ScopeX Family (Benchtop )

Copper Alloy Analyzer

    Copper Alloy Analyzer

    The copper alloy industry refers to the production and application industry that is based on copper and adds other elements such as zinc, tin, aluminum, nickel, etc. to form alloy materials with specific properties.Copper alloys have been widely used in many fields due to their excellent electrical conductivity, thermal conductivity, corrosion resistance and good mechanical properties. These fields include electronics and electrical, construction, automobile, aerospace, military industry, machinery manufacturing, etc. With the advancement of science and technology and the development of industry, the performance requirements for copper alloys are getting higher and higher, which prompts the copper alloy industry to continue to carry out material research and development and process innovation.


    ScopeX copper alloy special analyzer is a spectrometer specially designed by LANScientific for rapid analysis of copper alloys. It has the advantages of high precision, wide range of analyzable elements, simple and fast testing, etc. It can quickly analyze copper alloys.Instruments are not only used for product quality control, but also for research and development of new materials, monitoring of production processes, and waste recycling. Through accurate composition analysis, it helps manufacturers ensure that products meet standard requirements, while also promoting technological progress and sustainable development of the copper alloy industry.





    Advantage

    Data transmission

    USB, WIFI, wireless Bluetooth and other methods for data transmission.

    A variety of collimator, filter automatic switch

    5mm, 3mm, 1mm, 0.5mm four kinds of collimators, collimator and filter can be automatically switched by the software, save time and effort, through the appropriate collimator and filter or filter can improve the detection accuracy and sensitivity.

    User-defined

    The file can be in EXCEL, PDF and other formats. Users can customize the test report, including company logo, spectral spectrum and other sample information.

    Safety

    Fully enclosed metal chassis and leakage protection switch, more scientific design, hardware and software coordination, mechanical and electrical linkage, radiation safety in line with international standard.

    Application scenario

    铜合金专用分析仪(图1)

    Recovery and sorting of waste copper alloy


    铜合金专用分析仪(图2)

    Quality control and assurance of copper alloy

    铜合金专用分析仪(图3)

    Identification of copper alloy raw material/grades

    Product Parameters

    Range of element Na—U
    Sample room size 365mm×300mm×78mm(L×W×H)
    Maximum sample weight 0-2.5KG
    Cover open Automatic
    Mainframe size 570mm×400mm×400mm
    Weight 47KG
    X-ray tube High power side window X-ray tube,50W, pipe pressure pipe flow can be adjusted freely, W/Ag/Rh target (optional)
    Voltage Up to 50kV
    Current Maximum 1mA
    Cooling method Air cooling
    Type Si-pin/SDD(Optional)
    Sample observation 5 megapixel HD industrial camera
    CPU is I3-7100 with the same main frequency or above
    RAM DDR4 4 GB memory or above
    ROM 1TB HDD or 256GB SSD or above
    OS Windows 11
    Temperature conditions 10°C~35°C
    Relative humidity 40%-70% No condensation
    Power supply 220VAC
    Rated power 100W
