Coating thickness analysis has become an important part in processing industry and surface engineering quality inspection. It is a necessary means to verify whether products reach quality standards. In order to internationalize products, there are clear requirements for coating thickness for China’s export commodities and foreign-related projects.
ScopeX PILOT adopts down-top analysis design, equipped with advanced Multi-FP algorithm software, microlight aggregation technology and high-sensitive zoom distance measurement device. It can do fast, accurate and non-destructive testing on uneven, irregular and tiny samples.
It can easily deal with difficult problems in surface treatment process control product quality inspection and screening in coating field. ScopeX PILOT is widely used in jewelry, electroplating industry, automotive industry, hardware and bathroom, aerospace, electronic semiconductor and other fields.
|
|
Jewelry |
|
|
Electronic Component |
| Range of element | Al(13)-Fm(100) |
| Analysis of the layer number of | 5 layers (4 layers + substrate) each layer can analyze 10 elements, composition analysis can analyze up to 25 elements |
| X-Ray tube | 50 W (50 kV, 1mA) micro-focused tungsten palladium ray tube (target material is optional) |
| The detector | Si-Pin detector，high sensitivity SDD detector(optional) |
| Collimator | Φ0.1-Φ3optional |
| The camera | High resolution CMOS color camera, 5 megapixels |
| Manual sample XY platform | Moving range：50mm x 50mm |
| Filter | Fixed primary filter, multi-filter(optional) |
| Sample room size | 320mm × 480mm × 130mm（W×D×H） |
| Dimension | 330mm × 580mm × 360mm（W×D×H） |
| Weight | 40KG |
| Power supply | AC 220V±5V 50Hz(The configuration varies slightly by region) |
| Rated power | 150W |
